1800W MICRO INVERTER
Low DC voltage.
Components selected from world-class brands.
Built-in WiFi or additional monitoring device* available.
Adapts to any system size and optimizes space.
Fast installation and better adaptation to small systems.
Long 25 years lifetime，optional up to 20 yearswarranty.
Module-level optimization& monitoring.
Product Description
Model：FX-T1800ES
Input DC Data
Recommend Module Power Range(W)：[250W-650W+]*4
Maximum input voltage (V)：60V
MPPT voltage range (V)：22V-50V
Minimum start voltage [V)：16V
Maximum continuous input current (A)：20A*4
Maximum input short circuit current [A]：25A
Number of MPPT：4
Output AC Data
Maximum continuous output power[VA]：1600VA
Nominal output voltage/range [V]：220/230/[189~260)
Maximum continuous output current [A]：8.18A
Nominal frequency/range [Hz)：50Hz(47.5~52.5Hz]/60Hz[57.5~62.5Hz]
Power factor(adjustable]：+/-0.9
Total harmonic distortion：<3%
Maximum Units Per Branch (12AWG Cable)：2 Units
Maximum Units Per Branch(10AWG Cable)：3 Units
Efficiency
Peak efficiency：96.3%
MPPT efficiency：99.9%
Night power consumption [mW]：<100mW
Mechanical and Environ ment Date
Ambient temperature range[°℃)：-40~+65
Relative Humidity：0%~96%
Ingress Protection：IP67
Communication：PLCC/ Wi-Fi
