Introduction: Installing microinverters correctly is crucial for maximizing solar energy efficiency and system longevity. This guide walks you through the entire process for Envertech microinverters, from preparation to activation.

1. Preparation Start by bringing all equipment to the roof: microinverters, end caps, AC extension cables, screws, and tools. Plan your layout beforehand—sketch microinverter locations, grounding points, and cable routes to avoid errors during installation.

Minimize image

Edit image

Delete image

2. Installation Step 1: Mount Microinverters

• Use a tape measure to mark installation points under PV modules.

• Secure microinverters to the rack with screws, ensuring the LED side faces downward to avoid weather exposure.

Minimize image

Edit image

Delete image

Step 2: Grounding

• Fix screws to the microinverter’s installation holes.

• Ensure the screw thread pierces the bracket for optimal grounding and safety.

Minimize image

Edit image

Delete image

Step 3: Connect AC Cables

• Link microinverters serially by connecting AC connectors on both sides in a “hand-in-hand” configuration.

Minimize image

Edit image

Delete image

Step 4: Fasten Cables

• Use cable ties to secure AC cables to the rack, preventing damage or dislodging.

Minimize image

Edit image

Delete image

Step 5: Seal Unused Connectors

• Insert end caps into any unused AC cable connectors to protect against moisture and debris

Minimize image

Edit image

Delete image

Step 6: Connect PV Modules

• Plug DC input cables from each PV module into the corresponding microinverter.

Minimize image

Edit image

Delete image

Step 7: Grid Connection

• Use an AC extension cable to connect the microinverter series to the air switch.

• Link the distribution box to the local grid to complete the electrical setup.

Minimize image

Edit image

Delete image

Step 8: Activation

• Double-check all connections, then turn on the air switch.

• Within seconds, LED lights on the microinverters should flash, indicating successful operation.

Minimize image

Edit image

Delete image

Conclusion: Proper installation ensures peak performance and safety for your solar system. For professionals and DIY enthusiasts, following these steps will help you harness solar energy efficiently. WELTRUS supports installers and partners with high-quality products and resources—contact us to learn about distributor opportunities!
