FXC8V 100B

FXC8V High Voltage DC Contactor for energy storage systems. Reliable switching solution for industrial applications and renewable energy projects.

1.ceramic welding sealing technology, to achieve the contact part of the airtight packaging, no arc leakage risk, to ensure that no fire, no explosion;

2.in the airtight package structure, filling hydrogen-based gas, effectively prevent contact oxidation burning, low and stable contact resistance;

3.rated operating voltage maximum 750VDC, 100-250A 85℃ for a long time current carrying capacity;

4.meet the requirements of abnormal working conditions, can break 10 times the overcurrent;

5.insulation resistance up to 1000MΩ(1000VDC), medium voltage in line with IEC60664-1 requirements;

6.the series of products are mainly used in new energy vehicles main positive/main negative relay;
