10kV three-dimensional wound core liquid immersed distribution transformer

Three-dimensional wound core liquid-immersed distribution transformer: It breaks through the traditional planar structure. The three-phase magnetic circuit is completely symmetrical and the three-phase current is balanced; the volume and weight are smaller, the material consumption is less, and the utilization rate of the core material is higher; the reliability is high and the service life is long. The three-phase magnetic circuit is seamless, and the direction of the magnetic flux is completely consistent with the crystal orientation of the silicon steel sheet, which greatly reduces the no-load loss, no-load current and noise.

Low loss: meets the energy efficiency requirements of GB20052-2020 “Energy Efficiency Limit Values ​​and Energy Efficiency Grades of Power Transformers” standard;
Low noise: meets the requirements of the low noise standards of the State Grid and the Southern Grid;
Strong short circuit resistance: the low-voltage coil is wound with copper foil, and the high-voltage coil is cured and formed with glue paper, with high mechanical strength;
Beautiful appearance: full polishing and rust removal, powder spraying can achieve the effect of home appliance spraying;
